GLT+ Home Reverse Osmosis

Home-use Reverse Osmosis

Home hemodialysis applications are the best option for dialysis patients who prefer a flexible and more independent lifestyle.
The same devices and supplies used in dialysis centers can also be used for home treatment.
The key component for this is the purification system that produces the most necessary amount of dialysis pure water.
Reliability is crucial in a home-based RO device. It requires purification of dialysis pure water to the required levels and, at the same time, disinfection, ensuring the safety of dialysis treatment.
Our GLT+ Home RO model is designed for home dialysis systems. Thanks to our GLT+ Home RO device, dialysis patients can easily and comfortably receive their treatments in their own homes. One of the main challenges of the dialysis treatment process is transportation to dialysis centers, which results in inconvenience and time loss. A GLT RO device is essential for dialysis patients who choose home treatment.
The GLT+ Home RO device's premium osmosis unit will provide a pure water solution for home patients. You will be provided with training on the entire system, its special filter structure and disinfection system, as well as how to install and use the system in your home.

Product features

  • Adjustable alarm limits
  • Silent care, Compact power
  • Special design for the Home and ICU Room (intensive care unit)
  • Small Type membranes, Low-pressure switches
  • High-pressure pumps made from 316 L Stainless steel
  • Conductivity meter, Temperature meter
  • Permeate and reject water flow meters
  • Water inlet, RO membrane inlet, and outlet manometers
  • Touch screen option
  • Installation not required

Product Table

Specification

Details

Model

MHD2 MOBIL

Part Number

3025790 - 230 V, 50 Hz, 3 A

Nominal Product Flow Rate at 77°F (25°C)

1970 ml/min | 31.2 gallons/hr (118 liters/hr)

Dry Weight

75 kg

Power Range

230 V 50Hz 3 amps

Dimensions (Assembled Unit)

Wide - 45 cm | Depth - 75 cm | Height - 85 cm

Operational Parameters

TDS

Maximum: 1000 ppm

Ph with

Operating 5.5-8.5 | Cleaning: 2-11

Temperature Chloramines

40-90°F (4.4 - 32 °C)

Water Production decreases approximately 1.5% for every 1°F (3% for every 1 °C) increase in incoming water temperature.

Inlet pressure (Dynamic)

Minimum: 20PSI

Maximum: 80PSI

Mobil hardness:

Maximum: 25Fr

Silt Density Index (SDI)

<5

Note: The components are dictated in the detailed analysis of the feed water, if any. Needed before or after the treatment of the GLT+1-2 RO Home and ICU Room Mobil Osmos Unit
